You’ve Been Screwing It Up! The Shocking Truth About Tuff Rib Screw Placement!

Consult your dealer for recommendations for your particular roof. When it comes to installing a metal roof, one question that often sparks debate among homeowners and even contractors is this: Should you place metal roof screws on rib or flat sections of the panel? Incorrect placement can lead to leaks, premature wear, or even. Important notice this manual is to aid the installer with the installation of the tuf rib panel.

The 3 tuffrib panel may be installed vertically or horizontally on sidewall applications and verti cally on roof slope applications with a pitch of 3: (see diagram on pg. 7) metal panels should be installed with a #10 woodgrip screw with a neoprene washer (here after referred to as metal screws) in the flat of the metal of metal beside the major rib. (see page 4 for screw patterns. ) screws can also be screwed through the ribs.
